Lens Swarf Briquette Machines | Briquette Presses

Briquette press for unrivaled swarf management

The WEIMA briquette press reduces waste material handling and labor, saves money on waste disposal costs, and recovers up to 50% more coolant. Designed to work with 1 or 2 HC6 Microseparator® Systems, depending upon model.

Lens debris is automatically transported from Chip Separators to the WEIMA briquette press. Recovered coolant from the briquetting process is pumped back to the HC6 tank(s). With more than 4000 psi (275 bar) hydraulic pressure a briquette press offers around 95% of recovery of water and coolant.

Available in two configurations:

TH600 Vario briquette press supports 6 digital lens generator & works together with 1 Microseparators® HC6 or HC6 Plus System.
TH800 Vario briquette press support very large scale Rx-labs & works together with 2 Microseparators® HC6 or HC6 Plus Systems.

Large industrial laboratory machine with black metal frame, mounted modules, and multiple connected cables.

Hand holding a cylindrical white pellet above a container filled with many similar pellets.

Interior of a container coated with frost and ice buildup.

Close-up of industrial machine pipes and cylindrical components in a laboratory setting.

Close-up of a metallic screw conveyor mechanism inside industrial machinery.

Close-up of multiple cylindrical white pellets stacked together.

Tech Specs

Lens material:	All standard organic materials
Dimensions (wxdxh):	TH600 Vario 2300 x 2118 x 1553 mm / 90 x 84 x 62 inches TH800 Vario 2300 x 2069 x 2088 mm / 90 x 81 x 82 inches
Weight:	TH600 Vario 1000 kg / 2205 lbs TH800 Vario 3000 kg / 6600 lbs
