High throughput AR & Sun lenses coater

Capacity:up to 305 lenses/batch Ø 70 mm with ringless full dome
Supports multiple lens coating process applications: Anti-Reflective and/or mirror coating on organic and mineral eyeglass lenses via thermal evaporation process (PVD).
Deposition of multiple coating process features in one single run.
Larger Meissner trap shortens times to start the deposition, increases process repeatability, and throughput.
Powerful & fast diffusion pump system
Electron beam gun - highly flexible for selection & exchange of coating process (mirrors, AR, colors).
Simplified electron-beam emitter for easier maintenance & increased lens coating reliability.
Ion beam assisted deposition for best layer adhesion on various substrates.
Special gradient & planetary substrate holders (available upon request).

Large semiconductor processing system with enclosed chamber and side control panel featuring display screen.

Interior of semiconductor processing equipment with circular wafer holder and metallic chamber components.

Close-up of a circular wafer holder with multiple empty slots inside semiconductor processing equipment.

Interior view of semiconductor processing equipment with a large circular rotating wafer holder.

Processes

for clear AR & Sun lens coating

Top coating - Hydrophobic, Super Hydrophobic & Super Hydro/Oleophobic
AR coating - Premium, Performance
Mirror coating - Spectraflex X

1500-X, vacuum box coater can be customized to meet your product, process and production requirements.

Perfectly matched Satisloh ophthalmic lens coating processes, consumables, and box coaters guarantee best coating performance.

Tech Specs

6-sector dome lens capacity	Ø 65 mm up to 270 lenses/batch Ø 70 mm up to 246 lenses/batch
3-sector dome ringless lens capacity	Ø 70 mm up to 276 lenses/batch
Ringless full dome lens capacity:	Ø 70 mm 305 lenses/batch
Planetary cylinders lens capacity:	Available upon request
Lens material:	All organic materials and mineral glass
Dimensions (wxdxh):	2384 x 3295 x 2765 mm / 94 x 130 x 109 inches
Weight:	3900 kg / 8598 lb

All technical data subject to change without notice. Verify details with Satisloh.

Documents

1500-X – High-Volume box coater (Brochure)

pdf - 274 KB

Download

Person holding a tablet displaying charts and graphs from a production performance report.

Purchase a 1500-X and get a

MES-360 Lite for free.

Your introduction to Industry 4.0 with MES-360 Lite
Increasing transparency and visibility of your equipment performance is key to optimizing your production and reducing costs. MES-360 Lite provides daily reports using pre-established KPI to track.
